Use Cases
10.1.3
Choose Serial Protocol Type
The Temperature Regulator is using a request/response protocol to access parameters addressed
with index and sub index.
►
On the Serial RS232/485 page, select Modbus RTU.
10.1.4
Set Up Serial Communication
Set up the communication between the Communicator and the Temperature Regulator.
In the Serial RS232/485 page, configure the Communication settings.
Used the following settings:
Frame fields
Physical standard
Baud rate
Data bits
Parity
Stop bits
®
™
Anybus
Communicator
User Manual
Value
RS-232
19200 baud
8 bits
None
2 stop bit
89 (124)
SCM-1202-152 1.10 en-US
