Verify Operation
9.3
Ethernet LED Indicators
LED A
Off
Green
Green, flashing
Yellow
Yellow, flashing
LED B
Off
®
™
Anybus
Communicator
User Manual
Function
No link (or no power)
Link (100 Mbit/s) established
Activity (100 Mbit/s)
Link (10 Mbit/s) established
Activity (10 Mbit/s)
Function
Not used
87 (124)
SCM-1202-152 1.10 en-US
