Verify Operation
9.2

Communicator LED Indicators

Before you can verify operation you must configure the Communicator.
Operation Status
Off
Green, flashing
Green
Red
Red, flashing
Green/Red, flashing
® ™
Anybus Communicator User Manual
LED A LED B
Gateway status
EtherNet/IP - Adapter
No power
No power/Exception/No
IP address
Startup phase EtherNet/IP online, no
connections established
Operational EtherNet/IP online, one
or more connections
established
Exception/Fatal Duplicated EtherNet IP
address/Fatal error
error
Invalid One or more connections
timed out
configuration
Power up self-test/ N/A
Firmware update/
Firmware recovery
LED C LED D
Subnetwork Security switch
No power/Exception/ No power/Security
Subnetwork not switch is unlocked/
running Exception/Fatal error
Running, one or more
N/A
nodes are offline
Running Security switch is
locked
Fatal error N/A
All nodes are offline
N/A
N/A N/A
