Technical Data

8 Technical Data
Dimensions
Weight
Operating temperature
Storage temperature
Power supply
Current consumption
Housing material
Galvanic isolation
Protection class
CAN bit rates (CAN 1/CAN2)
CAN FD bit rates (CAN3/CAN4 withCANbridge NT 420)
Max. number of bus nodes
CAN bus termination resistor
CAN pass through delay
Startup time after power on
Processing time in Bridge mode
Startup time
CANbridge NT User Manual
114.5 x 99 x 22.5 mm
Approx. 150 g
-40 °C to +85 °C
-40 °C to +85 °C
9 V to 36 V DC with overvoltage and polarity
protection
Typically 110 mA at 24 V input voltage,
typically 220 mA at 12 V input voltage
Polyamide
1 kV DC for 1 sec
IP20
5 kbit/s to 1000 kbit/s
Arbitration rate: up to 1000 kbit/s, data rate: up to
8000 kbit/s (verified by testing)
User defined bit rates are possible. Depending on the
operating conditions (cable length, settings made,
remote stations, etc.) the maximum data might not be
reached or exceeded.
120
None
25-50 μs depending on configuration settings and CAN
load
< 1 s
30 000-40 000 msg/s
Min. 225 ms (configuration size 5 kB), max. 765 ms
(configuration size 140 kB)
