Use Cases
10.2.7
Check the I/O Data Map
The control word, speed from EtherNet/IP to My Drive and status word and actual speed from
My Drive to EtherNet/IP are mapped as follows in the I/O data map page.
Control word and speed from EtherNet/IP to My Drive
Address
0-1
2-3
Status word and actual speed from My Drive to EtherNet/IP
Address
0-1
2-3
®
™
Anybus
Communicator
User Manual
Data to EtherNet/IP
Control Word
Speed
Data from EtherNet/IP
Control Word
Speed
100 (124)
SCM-1202-152 1.10 en-US
