Check the I/O Data Map
The transactions to and from the Temperature Regulator are mapped as follows in the I/O data
map page.
Address
0–1
Address
0–1
®
™
Anybus
Communicator
User Manual
Data to EtherNet/IP
Setpoint temperature from EtherNet/IP to the Temperature Regulator.
Data from EtherNet/IP
Actual temperature speed from the Temperature Regulator to EtherNet/IP.
93 (124)
SCM-1202-152 1.10 en-US
