Procedure
1.
Add an Empty consume template and select it.
2.
Name the template Read Barcode Data.
3.
In the Frame editor, add four frame field with the following settings:
Consume frame fields
Frame
fields
Variable
data
Constant
Constant
®
™
Anybus
Communicator
User Manual
Name
Type
Value
Barcode
N/A
N/A
Data
Carriage
13
Byte (1
Return
byte)
character
(CR)
Line Feed
10
Byte (1
character
byte)
(LF)
Process
Fixed field Maximum
payload
data
delimiter
length
Yes, set
31 bytes
None
here
Yes, set
N/A
N/A
here
Yes, set
N/A
N/A
here
104 (124)
Subnet
End
delimiter
pattern
None
0
N/A
N/A
N/A
N/A
