1. Instrument Design

1.1. ecom-EN3/-R, Variant aluminium-framed
transport case
1
2
3
4
5
6
7
Holding clamp
1
for the probe
Connection USB
4
Battery and sensors
7
compartment
Condensation trap with
10
cooler and fine dust filter
Integral thermal printer
13
ecom-EN3
Graphic display
2
Connections for Pa
5
pressure sensor
Connection
8
sampled gas
Connection gas
11
temperature
Connection AUX
14
8
9
10
11
12
13
14
Slot for multi-media
3
card (SD)
Connection pressure
6
Connection draught
9
Connection air
12
temperature
