CAUTION
Data loss
When the "Format" menu item is selected and confirmed, all stored
data on the MM card inserted in the instrument will be irrevocably
deleted.

10.2 Data logger

When a MM card is inserted into the instrument, a data logger recording can
be performed. The measured values are stored one after the other on the
MM card depending on the recording interval set and are merged into a file
with the format * .csv.
The measured values can be evaluated using MS Excel or open office CALC.
NOTE
The data logger is ONLY available when a MM card is inserted into
the instrument.
The following adjustments are available in the Data processing / Datalogger
menu:
Parameter
Datalogger
Save to MMC
CSV-Header
If the data logger becomes active or becomes active again after an interrup-
tion, a new file is created on the MM card, in which all subsequent measured
values of the recording are saved. The files have a predefined name and are
numbered consecutively.
NOTE
Each measurement is assigned its own file with collected measured
values. Each file is automatically named and numbered.
Page 56
Meaning
Start, Stop Data logger
Adjustment of the interval time for
data logger recordings
Adjustment of data logging with or
without column headings
Adjustment
Yes, No
1 ... 999 s
On, Off
