1.6. Option hand soot pump set

Hand soot pump set
In order to perform a soot measurement in the flue gas from oil firing sys-
tems, a hand soot pump can be used.
By a prescribed number of suction strokes with the hand soot pump, a de-
fined amount of flue gas is drawn through an inserted filter paper. On the
basis of the deposited amount of soot on the filter paper (blackening), it is
possible to compare optically with a scale, which is the soot number. This
makes it possible to evaluate the amount of soot in the flue gas.
NOTE
The hand soot pump is TÜV tested and characterized by high quality
in its processing and construction. This guarantees a long-term reli-
able function.
NOTE
For further information on the procedure for soot measurement with
the hand soot pump, please refer to the manual for the hand soot
pump set.
