1.7. Option probe for flow measurement

Dynamic pressure probe
The flow velocity in the exhaust gas can be measured with the aid of a dy-
namic pressure probe. The dynamic pressure probe is available in lengths
of 250 mm, 1000 mm and 1500 mm. The maximum exhaust gas temperature
for using the probe is 300 °C.
NOTE
When using the dynamic pressure probe, the pitot factor must be set
to 0.93.

1.8. Option gas cooler

1
2
3
4
Gas outlet
1
Condensate evacuation
4
ecom-EN3
Gas inlet
2
Peltier element
5
KALT
Level monitoring
3
Fan
6
Page 13
