1. Instrument design
1.1. Basic module
Info display
(see chap-
ter 11.)
Connection
draught
Cable socket
by wire transfer
basic / control
modules
Basic
ON / OFF
Connection
AUX
Filter for
IR bench
SO2/NOx-
filter for
CO sensor
Integral
printer
Control
module
(see next page)
pro
ecom-J2KN
Connection
pressure
Connection mains
power plug
with fuse
(630 mA / 250 V)
Condensate
trap with fine
dust filter
Connection
gas hose
Connection
gas tem-
perature
Connection
air
temperature
Analogue
inputs
(Option)
Connections
pitot tube
(Option)
Connection
condensate
evacuation
Connection
heatet probe
(Option)
Page 5
