Ecom EN3 Instruction Manual page 38

1
D K O 9 7 2 / 2 2
2
3
4
5
Model name
1
Oil heater/
4
Air pressure monitor is on
Flame signal min
7
10
Valve 1 is on
Recording of operation stand (max. 120 sec.):
1/0 = Continuous phase
RZ = Ignition
FL = Flame identified
No error !
1
Number of startups total 677
Service counter actual
2
Further pages:
Page 38
OFF
OFF
228
Ignition is active
2
Operation voltage
5
Flame identified
8
Recording of operation
11
stand (max. 120 sec.)
RM = Fan motor
BV1 = Valve 1st stage
Err = Disturbance
Current error
142
2.3 1.2
1/0
RM
OV
RZ
BV1
BV2
FL
Err
3
6
9
OV = Oil preheater
BV2 = Valve 2nd stage
Use the cursor keys (Up / Down) to
call up further data of the firing auto-
mate. On the 2nd display page the
current error and the number of
burner starts are displayed.
