1. Instrument design
1.1. Basic module
(see chapter Control)
PTFE
filter 1
Fresh
air 1
Control
module
(see next page)
Fresh
air 2
PTFE
filter 2
Converter
cartridge
Integral
Page 6
Info display
Basic
ON / OFF
printer
Cable socket
by wire transfer
basic / control modules
Radio antenna
Connection mains
power plug
with fuse
(630 mA / 250 V)
Connection
pressure
Connection
Condensate trap
with gas cooler 1
and fine dust filter
Connection
gas hose
Connection
temperature
Connection
heated probe
pro
ecom-
J2KN
draught
air
TECH
