1. Instrument Design

1.1 ecom-EN3/-R, Transport variant aluminium-framed transport case

1
2
3
4
5
6
7
1
Holding clamp for
the probe
4
Connection USB
7
Battery and sensors
compartment
10
Condensation trap (with
peltier cooler) with fine
dust filter
13 Integral thermal printer
Page 8
2
Graphic display
5
Connections for Pa
pressure sensor
8
Connection sampled gas
11
Connection gas temperature
14 Connection AUX
3
Slot for multi-media
card (SD)
6
Connection pressure
9
Connection draught
12
Connection air
temperature
8
9
10
11
12
13
14
ecom-EN3
