7. After measurement

After the measurements have been completed, the following things have to
be observed BEFORE turning the instrument off.

7.1 Save measurement, print measurement

Once the gas analysis is completed and a memory place is chosen before,
transfer the values recorded in the intermediate memory on the MM card,
otherwise they would get lost by switch-off of the instrument. To store meas-
ured values permanently on the MM card, proceed as follows:
Press <Print> (printer symbol) to enter the printing menu.
--ECOM-EN3--
Start printout
View memory
Memory -> M
Input text
Select:
--ECOM-EN3--
Start printout
View memory
Memory -> M
Input text
Select:
--ECOM-EN3--
Start printout
View memory
Memory -> M
Input text
Select:
Page 44
The sampled data can be checked one more
time („View memory", <Enter> and scroll with
the cursor keys). The cursor keys can be used
to scroll through the measurement screens.
By selecting the "Insert text" menu item, the
plant identifier can be entered or changed.
See chapter "Gas analysis: Data processing"
for more information
All data correct? Then press „Memory -> M"
and <Enter> to transfer them in the internal
memory or on the MM card ("Symbol memory"
is shown in black in the measurement mode).
The inputted text is taken over into the data rec-
ord only by transfer on MM card.
