4. Measurement procedures

4.1. Gas analysis

The measurement procedure for gas analysis can be used for most control
measurements in order to determine the gas components, temperatures and
ratios in the measured combustion process. The following measurement dis-
plays are available for the gas analysis procedure:
O2
1
CO2
T.Gas
T.Air
2
Gas analysis
3
O2
CO2
CO
4
Eff.
Losses
Exc. air
T.Gas
T.Air
5
Gas analysis
T.Gas
180.4
Gas analysis
Switch-off CO-Sensor
1
key <F3>
Symbol cooler ON /OFF
4
Page 22
3.2
%
13.1
%
184
°C
20
°C
3.2 %
13.1 %
0 ppm
92.5 %
7.5 %
1.18
184 °C
20 °C
°C
Hotkey key <F1>
2
Hotkey key <F4>
5
Measurement display: Gas analysis 1 + 2
Measurement display: Gas analysis 3
Measurement display: Gas analysis 4
Store and print values
3
key <F2>
ecom-EN3
