1.2. ecom-EN3-F, Variant professional case

1
2
3
4
5
6
7
Holding clamp
1
for the probe
Connection Pressure
4
Connection USB
7
Condensation trap with
10
cooler and fine dust filter
Connection air
13
temperature
Page 8
Battery and sensors
2
compartment
Connections for Pa
5
pressure sensor
Integral thermal
8
printer
Connection draught
11
Connection AUX
14
8
9
10
11
12
13
14
Grafic display
3
Slot for multi-media
6
card (SD)
Connection
9
sampled gas
Connection gas
12
temperature
ecom-EN3
