The following functions are available in all 4 measurement displays:
Pressing <F1> enables to switch, from the values display, to a menu point
selected before or on „Standby" (see chapter Adjustments). Possible menu
points are: Soot...Oil trace, Data processing, View memory, Display values,
Fuel type, Efficiency (K), Internal, Adjustments. Furthermore you can switch
back from any random menu point to the values display with <F1>.
Press <F2> to print out the values simultaneously to their recording in the
intermediate memory.
Press <F3> to cut the CO sensor from the gas path so that it is protected
against too high concentrations. The automatic switch-off takes place at
2500 ppm or 4000 ppm (depending on the model).
The following function is also available in the measurement screens 1..3:
Pressing <F4> also enables to switch, from the values display, to a menu
point selected before or on „Standby" (see chapter Adjustments).

4.1.1 Adaptation of the displays for gas analysis

NOTE
The position of the measured and calculated values (gas analysis
sub-menu) on the display pages is free selectable
For alteration of the existing succession, proceed as follows:
•
press <Enter> / „Display values" / <Enter> to activate the function
•
select line with cursor keys (Up/Down)
•
select desired parameter with cursor keys (right / left)
•
repeat procedure until desired layout is completed
•
press <Enter> to deactivate the function
The measured value or the calculation value in measurement screen 4 can
be set with the cursor keys (right / left).
