10. Data processing

10.1 Storage on MM card

NOTE
When an MM card is inserted into the instrument, it is used to store
measured values and plant data. This storage must be triggered
manually or can be automated (data logger).
Data processing
Select
View
Memory (M)
Format
Quit with:
DRT <-> PC!
Datalogger
Date
1 01.09.14 11:01
2 01.09.14 11:02
3 01.09.14 11:04
4 01.09.14 11:07
5 01.09.14 11:11
6 01.09.14 11:23
7 01.09.14 11:44
8 01.09.14 11:53
Select:
Single measurement results can be called up as follows:
• select desired record number with the cursor keys and confirm with <En-
ter>
• confirm desired record number with <Enter>
• scroll with the cursor keys <up/down>
• press <ESC> to exit
By selecting the "Format" menu item, the entire MM card can be formatted.
This function is usually needed by initial adjustment of the instrument at our
factory (preparation of MM card for data recording).
ecom-EN3
By selecting the menu item "Select", plants for
the assignment of measured values can be
searched for or set up (for further information
see chapter "Gas analysis: Data processing").
By selecting the menu item "View", stored
measured values can be viewed (for further in-
formation see chapter "Gas analysis: Data pro-
cessing").
Fuel type
Fuel oil
Fuel oil
By selecting the menu item "Memory (M)", all
Fuel oil
stored measurements (sorted by record num-
Fuel oil
Fuel oil
ber) can be viewed.
Fuel oil
Fuel oil
Fuel oil
