Replace The Printhead Cartridge - DataCard ImageCard User Manual

4-12
14 Lift the printhead cartridge up and off the swing arm (step 2 in
15 Push the locking tabs to the side. Remove the printhead cable

Replace the printhead cartridge

1
2
3
4
Figure 4-10).
from the printhead cartridge (see
Figure 4-11: Remove or replace the printhead cable
Push the printhead cable into the new printhead cartridge (see
Figure 4-11). Make sure the locking tabs are in place.
!
Do not press on the wires of the printhead cable.
Align the printhead cartridge pins with the printhead cartridge
slots on the swing arm (see
Slide the new printhead cartridge onto the swing arm, so the pins
slide into slots (step 1 in
Hold the printhead cartridge latch lever down (step 2 in
Figure 4-12) and pivot the printhead cartridge down toward the
swing arm (step 3 in
Be sure that the tabs on the back of the printhead cartridge fit into
the notches on the swing arm spring bar securely (location A in
Figure 4-12). Release the latch lever when the printhead
cartridge is in place.
Figure 4-11).
Figure 4-12).
Figure 4-12).
Figure 4-12).
User's Guide for the Magna™ Class Printer
Maintaining the printer
