DataCard ImageCard User Manual page 35

2-16
Replace the print ribbon cartridge
1
2
3
4
Ribbon supply
Figure 2-15: Load new print ribbon on the ribbon cartridge
Place the ribbon cartridge onto the ribbon cartridge supports, and
press down until it clicks into place (see
Print ribbon supply
Figure 2-16: Replace the print ribbon cartridge
Close the swing arm, pressing it down until the push latch clicks
into place.
To close the cover, lift the top slightly. Move the support up so it is
parallel with the hinges, and lower the cover.
If you are installing the print ribbon for the first time be sure to
print a printer test card after installing the printer driver. (See
"Making and evaluating test cards" on page 2-29
information.)
Ribbon take-up
Figure
Ribbon take-up
User's Guide for the Magna™ Class Printer
Getting started
2-16).
for more
