DataCard ImageCard User Manual page 25

2-6
4
5
6
7
8
2
1
Figure 2-3: Unpack the printer
Remove the accessories box (step 2 in
Open the top of the packing material (step 3 in
The printer weighs 36 to 45 pounds (16.4 to 19.5 kilograms).
Use proper lifting techniques. Make sure you have enough
people to lift the printer comfortably.
Lift the printer from the carton (step 4 in
on a counter or other solid surface.
If the end of the packing material comes out of the box, slide it off
the end of the printer and place the entire printer on a counter or
other solid surface.
i
Save all packing material, including the plastic bag, shipping
carton, shipping cushions, and accessories box.
Open the accessories box and remove the contents. The
accessoris box contains:
– Card output stacker
– Power cable
– Interface cable
– Warranty and declaration of conformity
4
3
Figure
Figure
User's Guide for the Magna™ Class Printer
Getting started
1
2-3).
Figure 2-3).
2-3) and place it
