Overview

Printer features

Use the information in this section to identify the features and controls
you use on the printer.
Front of the printer
Find the following on the outside of the printer:
Card cartridge
The card cartridge holds blank cards to print. It holds about 100 cards
(with a nominal thickness of 0.030 inches (0.76 mm)). At the bottom
of the card cartridge, the exception card slot allows you to insert a
single card that is different from the cards in the card cartridge.
User's Guide for the Magna™ Class Printer
The ML and M2L models of the printer include the overlay
module which applies a durable polyester patch (overlay) to one
or both sides of the personalized card. You can select the type
and thickness of the overlay to use.
Top cover support
Duplex module
Swing arm
Cover
Card cartridge
Exception card slot
Ready button
Status light
Figure 1-4: Front of the Magna Class printer
Overlay module
Overlay supply
cartridge
Print ribbon cartridge
Printhead cartridge
Manual card
feed knob
1-5
Card output
stacker
Overlay card
feed knob
