User's Guide for the Magna™ Class Printer
The Conflicting device list should show No conflicts.
If you are using a DMA channel for the second printer, the
Resources settings list should show Direct Memory Access and
its channel setting.
Figure C-1: Printer Port (LPT) Properties dialog box
If the Resources tab shows conflicts, select another configuration
or change the settings for the port, following port instructions.
Click OK on the Printer Port (LPT2) Properties dialog box and on
the System Properties dialog box to save settings and close the
dialog boxes.
i
If you install the second parallel port and receive Windows errors,
or if the printer does not print reliably (without displaying errors),
the port might have an unresolved hardware conflict. Contact the
port manufacturer or the PC manufacturer for assistance.
C-3
