P C settings
C
This appendix provides information about
the PC on which the Magna Class printer
driver is installed. It describes:
•
•
•
•
This appendix includes a section for settings that are handled the
same way in all operating systems and also includes sections for
each PC operating system supported by the printer driver.

PC settings for all operating systems

This section describes how to configure the ECP parallel port.

Configuring the ECP parallel port

For most PCs, the parallel port is configured as an ECP parallel port
in the PC's BIOS. See the information that accompanies your PC for
details about changing the BIOS settings. The following applies to
most PCs and to the Windows NT and Windows 98 operating
systems.
Configure the ECP parallel port
1
2
3
4
User's Guide for the Magna™ Class Printer
Configuring the ECP parallel port
Setting port values
Setting printer permissions (Windows NT only)
Configuring the optional smart card serial port
Close all open applications.
Reboot the PC.
Enter Setup and follow the instructions that display early in the
reboot sequence. The setup screen will appear.
In Setup, check to see that the Parallel Port Mode field is set to
ECP. If it is not, set it to ECP.
