Overlay Material - DataCard ImageCard User Manual

B-4
i
appropriate changes to the Magna Class printer driver. See
"Changing the type of print ribbon" on page

Overlay material

Use Datacard's DuraGard™ overlay material in the Magna Class
printer.
The following describes the overlay materials you can use:
If you change the type of ribbon you use, be sure to make the
Name Part number
DuraGard 557171-001
Overlay supply
0.5 mil
DuraGard 557171-101
Overlay supply
1 mil
DuraGard 557171-002
Smart card
overlay supply
0.5 mil
DuraGard 557171-102
Smart card
overlay supply
1 mil
Holographic 547562-001
overlay supply
0.6 mil
5-13.
Description
Full-card die-cut polyester patches
on a carrier material.
About 300 uses.
Full-card die-cut polyester patches
on a carrier material.
About 250 uses.
Die-cut polyester patches, 0.5 mil
thick, on a carrier material. Patches
cover all of the card except the area
of the smart card chip.
About 300 uses.
Die-cut polyester patches, 1 mil
thick, on a carrier material. Patches
cover all of the card except the area
of the smart card chip.
About 250 uses.
Die-cut polyester patches on a
carrier material with a tamper-
evident image.
About 250 uses.
User's Guide for the Magna™ Class Printer
