PC settings for Windows 98

This section describes the following settings for PCs running
Windows 98.
•
User's Guide for the Magna™ Class Printer
Select the Settings button to display the port settings.
i
If the PC has more than one serial port, make sure you view
the settings for the serial port to which the printer is attached.
Figure C-3: Settings dialog box
Select the following settings:
Setting
Baud rate
Data bits
Parity
Stop bits
Flow control
When the settings are correct, click OK to save settings and close
the dialog box.
Setting port values
Value
9600
8
None
1
None
C-7
