Printer components

The Magna Class printer has a replaceable printhead. In addition,
you can order additional or replacement parts for the printer. This
section describes the printer parts you can order.

Printhead cartridge

The Magna Class printer has a replaceable printhead. The printhead
is subject to wear and has a direct impact on print quality.
Select the printhead to order based on the printer series.The
following printheads are available.
Printer
series
ImageCard
UltraGrafix
Keep a replacement printhead in stock so it is available when you
need it.
User's Guide for the Magna™ Class Printer
Printhead
type
Full color
Monochrome
Printhead type label
Printhead-do not
touch this surface
Figure B-6: Magna Class replaceable printhead cartridge
Do not touch the printing edge of the printhead in the printhead
cartridge. If you do, use the cleaning pen to clean it. See
"Cleaning the printhead" on page
Printhead type label Part number
Three colors
All black
4-6.
B-11
547675-001
547674-001
