Use The Properties Dialog Box - DataCard ImageCard User Manual

3-2
The Default Document Properties dialog box also provides access to
the About dialog box, which shows the printer driver version.
Settings that control the non-printing operation of the printer are in the
Properties window for the printer. These settings include:
•
•
E
The Magna Class printer driver provides help for the Default
Document Properties dialog box and Windows NT provides help for
the Properties dialog box. Help provides information about specific
settings of the Magna Class printer driver. Help does not include step-
by-step procedures or detailed conceptual information.

Use the Properties dialog box

Make sure the printer power is on and the printer is connected to the
PC.
1
2
3
4
Port to which the printer is attached
Permissions for other users of the PC
Select Start from the Windows NT taskbar.
From the Windows NT Start menu, select Settings and then
Printers. The Printers window appears.
Click once on the Magna Class printer driver icon.
Select File from the Printers menu bar, and then select
Properties. The Magna Class Properties dialog box appears.
User's Guide for the Magna™ Class Printer
Using the printer
