Getting started
4
5
6
7
8
9
10 Wind the supply material in front of the guides and around the
11 Press the label onto the take-up spool to secure the supply
User's Guide for the Magna™ Class Printer
Remove the empty spool from the supply spool holder and press
the spool into place on the take-up spool holder of the cartridge
(step 1 in Figure 2-18). Make sure the ribs inside the spool align
with the grooves in the spool holder.
Press on the spool and turn the spool slightly (if needed) until the
spool fully covers the spool holder ribs.
Unwrap the new overlay supply material.
Place the full supply roll on the right spool holder as you face the
open side of the cartridge (step 2 in
supply will unroll counterclockwise
Take-up spool
4 1
Figure 2-18: Load overlay in the cartridge
Make sure the ribs inside the spool align with the grooves in the
spool holder. Press on the spool and turn the supply roll slightly (if
needed) until the spool fully covers the spool holder ribs.
Lift the label on the supply roll and unroll about 8 inches from the
supply roll.
take-up spool (step 3 in
will wind counterclockwise
material, as shown (step 4 in
Figure 2-18). Make sure the
, as shown.
Supply roll
3
Figure 2-18). Make sure that the material
.
Figure 2-18).
2-19
2
