Getting started

Printer test card

The printer test card is designed to perform most of the functions
available in the printer.
Check the following:
•
•
•
See
about magnetic stripe tracks.
User's Guide for the Magna™ Class Printer
Figure 2-24: Printer test card
The test card has the pattern shown on the front of the card. The
back of the card is unprinted.
If a topcoat (T) panel is included in the ribbon and you select a
ribbon type that applies topcoat to the front of the card, the front
of the card has topcoat applied.
If a magnetic stripe module is installed in the printer and enabled,
the following data is encoded on the card:
Track Format
Track 1 (IATA)
Track 2 (ABA)
Track 3 (NTT)
Track 3 (TTS)
"Magnetic stripe encoding" on page D-1
icivtc
Data
TEST PATTERN IATA CHARACTER
SUBSET 0123456789
012345678012345678990123456789
0123456789=9876543210
0123456789=9876543210
2-31
for more information
