Verify the debower position

The debower in the optional overlay module should be set for the type
of cards you print. The debower assures that the heat used to apply
the overlay does not leave cards bowed or curled.
User's Guide for the Magna™ Class Printer
Push the overlay cartridge into the printer (step 1 in
Make sure the supply material passes between the heated roller
and the platen roller. Turn the supply knobs if needed to take up
slack so the material does not wrinkle as the cartridge is pushed
in place.
Hold the back of the printer and push firmly on the overlay
cartridge to seat it in the printer.
E
If the cartridge becomes stuck part of the way into the station,
turn the supply and take-up knobs clockwise
spindle ribs fit between the spool ribs.
Press the cartridge lock to secure the overlay cartridge in the
printer (step 2 in Figure
Lower the supply tracker until it rests on the supply material (step
3 in Figure 2-19).
Verify that the cartridge is replaced correctly by making sure the
locating posts come through the locating holes in the cartridge
(Figure 2-19).
E
If needed, release the cartridge lock and seat the cartridge
completely. Press the cartridge lock again.
To close the cover, lift the top slightly. Move the support up so it is
parallel with the hinges and lower the cover.
2-19).
2-21
Figure 2-19).
slightly so the
