Loading overlay in the cartridge

After removing the overlay cartridge from the printer, remove the used
overlay material and load new overlay material.
Load overlay in the cartridge
1
2
3
1
Figure 2-17: Remove the overlay cartridge
Pull out on the cartridge lock to release the overlay cartridge
(step 2 in Figure 2-17).
Pull the overlay cartridge out until the cartridge is out of the
printer (step 3 in Figure
Place the overlay cartridge upside down on a level surface, such
as a table, with the wide side away from you.
Pull up firmly on the full take-up spool to remove it.
Remove the end of the supply material from the empty supply
spool if needed. Dispose of the used supply according to your
policy.
2-17).
