Replacing The Overlay Cartridge - DataCard ImageCard User Manual

2-20
12 Pick up the overlay cartridge and turn it over. Turn the overlay
The overlay cartridge is ready to be replaced in the printer.

Replacing the overlay cartridge

When replacing the overlay cartridge, begin with the top cover open.
Replace the overlay cartridge
1
2
take-up knob clockwise
material.
E
Make sure the supply tracker is raised and out of the way. See
Figure 2-17.
Hold the loaded overlay cartridge next to the overlay station, with
the cartridge handle toward you.
Align the overlay cartridge so the spools in the cartridge are even
with the spindles in the station.
3
Figure 2-19: Replace the overlay cartridge
to remove any slack in the supply
User's Guide for the Magna™ Class Printer
Getting started
2
1
