No. Interface
1 Lens Mount
2 Screw Hole
3 USB Interface
CoaXPress Area Scan Camera
Figure 2-4 Appearance (Type IV)
Figure 2-5 Appearance (Type V)
Figure 2-6 Appearance (Type VI)
Table 2-1 Component Description
Description
It is used to install lens. Refer to the camera's specification for
details.
It is used to fix the camera to the installation position. Refer
to the camera's specification for details.
It is used to update firmware.
