 Binning Horizontal refers to the image's width, and Binning Vertical refers to the image's
height.
 For different models of camera, the binning function may be different, please refer to the
actual one you got.

10.7 Set Decimation

The decimation feature allows you to reduce the number of sensor pixel columns or rows that are
transmitted by the camera. This procedure is also known as "subsampling". It reduces the amount
of data to be transferred and may increase the camera's frame rate.
Click Image Format Control, and set Decimation Horizontal and Decimation Vertical according to
actual demands.
The figure above is the graphical user interface from Matrox CoaXPress frame grabber client
software.

10.8 Set Exposure Time Mode

The camera supports exposure function, and exposure includes Ultrashort mode and Standard
mode.
For specific expose mode and range that the camera supports, please refer to the specifications of
the camera.
Under Ultrashort exposure mode, the camera exposes within an ultrashort time, and you can
adjust exposure time manually only.
CoaXPress Area Scan Camera
Figure 10-13 Set Binning
Figure 10-14 Set Decimation
User Manual
·
51
