7.5.4 Set Trigger Activation

The camera supports trigger acquisition in the rising edge, falling edge, level high, or level low of
the external signal. The principle and parameter of trigger activation are as follows.
Specific trigger activation parameters may differ by camera models.
Trigger Activation
Rising edge
Falling edge
Level High
Level Low
Click Acquisition Control > Trigger Selector > Trigger Activation, and select Rising Edge, Falling
Edge, Level High or Level Low as Trigger Activation according to actual demands.
CoaXPress Area Scan Camera
Table 7-4 Trigger Activation Principle and Parameter
Parameter
Acquisition Control >
Trigger Selector >
Trigger Activation
Acquisition Control >
Trigger Selector >
Trigger Activation
Acquisition Control >
Trigger Selector >
Trigger Activation
Acquisition Control >
Trigger Selector >
Trigger Activation
User Manual
·
Parameter Value
Rising Edge
Falling Edge
Level High
Level Low
27
Principle
When the level signal sent by
external devices is in rising edge,
the camera receives trigger signal
and starts to acquire images.
When the level signal sent by
external devices is in falling edge,
the camera receives trigger signal
and starts to acquire images.
Level High refers to the level high
of the trigger signal is valid. As
long as trigger signal is in level
high, the camera keeps exposure
and acquisition status.
Level Low refers to the level low of
the trigger signal is valid. As long
as trigger signal is in level low, the
camera keeps exposure and
acquisition status.
