Precor Experience 700 Series Service Manual

Hide thumbs Also See for Experience 700 Series:
Table of Contents

Advertisement

Quick Links

Service Manual
Experience™ Series 700 line
TRM700-16/18 Treadmills

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Experience 700 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Precor Experience 700 Series

Summary of Contents for Precor Experience 700 Series

  • Page 1 Service Manual Experience™ Series 700 line TRM700-16/18 Treadmills...

  • Page 2: Table Of Contents

    Specification Summary Fastener Torque Specification Calibration Specification Belt Tension Specification Bolt Grade Identification Bolt Grade Markings Chart Parts Lubricants Cleaning Procedure Approved Cleaning Products Cleaning Procedure Power Requirements Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page ii any questions.
  • Page 3 Diagnostics menu access Touchscreen Display Calibration shortcut Debug Information Report shortcut Navigating the Service Menus P10, P30, P30i and P31 LED consoles P10, P30 and P31 consoles Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page iii any questions.
  • Page 4 Drive Belt Tension and Alignment Adjustment About Specifications Procedure Legacy Frame Drive Belt Tension and Alignment Common Frame Drive Belt Tension and Alignment Running Belt Tension and Tracking Adjustment About Videos Tools Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page iv any questions.
  • Page 5 Dash Top and Bottom Cover Replacement Side Arm Upper/Lower Covers Replacement Power Cord Replacement About Procedure ON/OFF SW Circuit Breaker Replacement About Wire Diagram Procedure ASL PCA Replacement Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page v any questions.
  • Page 6 Common Frame Drive Belt Replacement Drive Motor Replacement About Procedure Legacy Frame Drive Motor Replacement Common Frame Drive Motor Replacement Drive Roller Replacement About Procedure Legacy Frame Drive Roller Replacement Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page vi any questions.
  • Page 7 Validate the customer reported issue Verify Input Power Verify (reproduce) the customer issue Verify the Club Settings Verify service bulletin and software update incorporation Verify console operation Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page vii any questions.
  • Page 8 Input Power Troubleshooting Console Power Troubleshooting Communications Error Troubleshooting Machine Controls Troubleshooting Auto Stop Troubleshooting E-Stop not Communicating Troubleshooting Heart Rate Monitor Troubleshooting Drive Motor System Troubleshooting Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page viii any questions.
  • Page 9 Ordering Parts Common Frame Drive Roller Common Frame Take-up Roller Common Frame Running Deck Landing Trim End Cap Covers Drive Belt Tension Adjustment Dust Guard System Wiring Diagram Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page ix any questions.
  • Page 10 Parts List - Common Frame Appendix A : Edition Information Edition Additional Documentation Copyright Appendix B : Notices and Safety Trademarks Intellectual Property Warranty Safety Notices Service Safety Guidelines Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page x any questions.

  • Page 11: Introduction

    Introduction Only Precor certified technicians are authorized to service Precor equipment. If you are not a Precor certified servicer, you must not attempt to service any Precor product. Call your dealer for service information WARNING: This service documentation is for use by Precor certified servicer pro- viders only.

  • Page 12: Service Manual Contents

    Common Frame Update Precor has implemented a new common frame weldment starting 05/14/2019 that is used on the TRM600, TRM700, and TRM800 Experience™ Series treadmills. This manual will provide separate service information for both the original "Legacy" frame and new "Com- mon"...
  • Page 13 1 Introduction Additional Service Documentation and Videos "Parts " on page 302 Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page 3 any questions.

  • Page 14: Service Safety Guidelines

    Service Safety Guidelines WARNING: Only Precor certified servicers and technicians are permitted to ser- vice Precor products. Personal injury can result from electrical shock and/or mech- anical moving parts. Review the following safety information prior to servicing the equipment. This safety inform- ation will help to prevent personal injury or damage to the equipment while servicing the equipment.
  • Page 15 Remove jewelry (especially from ears and neck). Tie up long hair. Remove neck ties. Do not wear loose clothing. See Also "Notices and Safety" on page ii "Safety Notices" on page iii Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page 5 any questions.

  • Page 16: General Information

    Alternating Current: electric current which periodically reverses direction between positive and negative polarity. Motor controller, motor controller unit, or motor controller module: used on treadmills, con- tains the LPCA and motor controller functionality. Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page 6 any questions.
  • Page 17 Ground Effects Impact Control System: Patented treadmill design that out performs a nat- ural running surface, absorbs high-impact movement, reduces joint stress and minimizes fatigue and supports a solid and controlled push off. Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page 7 any questions.

  • Page 18: Model And Serial Numbers

    EFX: Mov Ramp/Mov SCL StairClimber Arms 4-Precision, Con- RBK: Standard features sumer UBK: Standard features 2-Energy, Consumer Treadmill Elliptical Fitness Crosstrainer Adaptive Motion Trainer Upright Bike Recumbent Bike Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page 8 any questions.

  • Page 19: Serial Numbers

    Note: Always use the frame serial number label to verify the machine serial num- ber. Do not use a label attached to a plastic cover, the cover may have been Spinner Indoor Cycle Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page 9 any questions.

  • Page 20: Orientation

    The equipment orientation (front, right, left, & back) is referenced to an exerciser standing on the running belt/deck facing the console. Covers and Panels Covers and Panels Equipment cover and access panel locations. Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page 10 any questions.

  • Page 21: Tools And Supplies

    • US & metric Allen wrench set • Cutters • 7/16” Allen key, socket mounted • Rubber mallet • Pliers • Tape measure /Straight edge ruler • Inner and outer snap ring pliers Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page 11 any questions.

  • Page 22: Specification Summary

    6 ft-lb is equivalent to 6 lbs of force applied 1 foot away from the center of the bolt. Heart Rate Radio Frequency: Identifies electromagnetic signals with frequency spectrum between the 3 kHz (3,000 hertz) to 300 GHz (300 billion hertz) range. Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page 12 any questions.

  • Page 23: Calibration Specification

    Bolt grade markings are used to categorize bolts according to the bolt material, man- ufacturing process, and mechanical properties. The grade of the bolt is stamped on the head of the bolt. Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page 13 any questions.

  • Page 24: Bolt Grade Markings Chart

    Parts IMPORTANT: Always purchase OEM replacement parts and hardware from Pre- cor. If you use parts not approved by Precor, you could void the Precor Limited War- ranty. Use of parts not approved by Precor may cause injury. There is a copy of the parts Exploded View Diagram and Parts Identification List included in the Parts chapter (see Parts)that you can use as a quick reference.

  • Page 25: Lubricants

    1 part mild soap to 30 parts water (recommend Simple Green cleaner or equi- valent). Athletic equipment cleaner, 9x7 pre-saturated wipes (ATHLETIX PRODUCTS). Enivir O Safe oxygen enhanced cleaner or Enviro Safe glass and multitask cleaner concentrate. Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page 15 any questions.

  • Page 26: Cleaning Procedure

    Generic cleaning procedure applicable to all Precor equipment: TIP: There are many product specific PREVENTATIVE MAINTENANCE cleaning videos available on the Precor Connect SERVICE VIDEOS web page. Log in to your Precor Connect servicer account and select SERVICE VIDEOS, see SERVICE VIDEOS.

  • Page 27: Plugs And Outlets

    Individual branch circuit requirement (US and Canada installations) Each Precor treadmill must be connected to a separate 20 amp individual branch circuit out- let. No other devices can be connected to the same circuit outlet except for one optional PVS (Personal Viewing System) display if installed.
  • Page 28 Your equipment comes with a power cable that meets your local electrical code require- ments along with the equipment. Precor commercial treadmills must be connected to a 20 amp individual branch circuit that can be shared only with one PVS.

  • Page 29: Console & Pvs Display Power Requirements

    The machine power cord must be plugged in and switched ON to power up and use the console. The console power is independent of the machine workout oper- ation. Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page 19 any questions.

  • Page 30: Touchscreen Consoles (P62, P80, And P82)

    43 W max AC/DC adapter specification: AC/DC Adaptor Specification input voltage 100v-240v output power rating 60W/12Vdc/5A Direct Current: electrical current that only flows in one direction. Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page 20 any questions.

  • Page 31: Cable Tv Rf Power Requirements

    N after the receiver filters: in terms of power: CNR = C/N, in terms of decibels CNR (dB) = 10Log(C/N) = C (dBm) – N (dBm). Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page 21 any questions.

  • Page 32: Ethernet (Lan) Input Signal Requirements

    The touchscreen consoles P62, P80, and P82) use a security token for communication to the Precor servers. The security token is a hash string that is sent with every API call from the FE’s to the Amazon Cloud. The security token originates after the equipment is registered at the location.
  • Page 33 2 General Information Equipment Spacing Requirement Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page 23 any questions.

  • Page 34: Operation Verification

    1. Access the Service menu (51765761) and perform the following console System Tests (Settings > System Settings > System Tests): Touchscreen Calibration: Follow screen prompts to complete test. Touchscreen console Control Processing Assembly. Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page 24 any questions.
  • Page 35 Verify that the lift motor operation is smooth while changing the INCLINE from minimum to maximum levels. Verify that the console INCLINE level indicators and user workout displays are showing correct information. Running Belt Test (Internet Only) Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page 25 any questions.
  • Page 36 Emergency Stop: Safety clip and lanyard attached to the stop switch to immediately turn off power bringing the treadmill to a stop. Handheld Handlebar Heart Rate Heart Rate Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page 26 any questions.
  • Page 37 4. On successful completion of all verification tests, return to service. ANT+ (pronounced ant plus) is a wireless protocol for monitoring sensor data such as a person's heart rate or a bicycle's tire pressure Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page 27 any questions.

  • Page 38: Standard Service Menus

    Standard Service Menus About There is a set of equipment Standard Service Menus that are supported across Precor car- dio product lines designed to allow servicers and clubs to manage, configure/setup, and maintain/test the equipment: The service menus are grouped into functional service cat-...

  • Page 39: Touchscreen Consoles: P62, P80, And P82

    Note: Service access code 65 "Information Display" is not used on touchscreen consoles. The Information Display menus are integrated into the Service Settings menus. Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page 29 any questions.

  • Page 40: How To Access The Standard Service Menus

    Have the service access code ready and then use the following instructions to access the standard service menu: Steps: P10/P30/P31 Press the PAUSE hardkey and immediately use the keypad to type in consoles: the access code. Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page 30 any questions.

  • Page 41: P80 Touchscreen Console

    3. Use the touch keypad to type in the service access code. P62 and P82 touchscreen consoles Diagnostics menu access Have the service access code ready and then use the following instructions to access the standard service menu: Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page 31 any questions.

  • Page 42: Touchscreen Display Calibration Shortcut

    2. Press and hold the VOL down key while pressing CH up >CH down > CH down > CH up: 3. At the Sign-In screen, type in the service access code. Touchscreen Display Calibration shortcut Console shortcut to access the Touchscreen Calibration test. Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page 32 any questions.

  • Page 43: Debug Information Report Shortcut

    Short for Universal Serial Bus, is an industry standard developed in the mid-1990s that defines the cables, connectors and communications protocols used in a bus for connection, communication, and power supply between computers and electronic devices. Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page 33 any questions.
  • Page 44 4 Standard Service Menus How to Access the Standard Service Menus IMPORTANT: Do not remove the USB drive until the "Report was successful" mes- sage is shown, (approx. 1 min). Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page 34 any questions.

  • Page 45: Navigating The Service Menus

    Error Log or show the "Stuck Key" mes- sage when there are no logged errors. INCLINE numeric keys Use as the numeric keypad to type in numeric inputs (access codes etc.). Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page 35 any questions.

  • Page 46: P80 And P82 Touchscreen Consoles

    Scroll Up/Dwn Use your finger to select while swiping your finger Up/Dwn to scroll through menu lists. Some menus provide an on-screen scroll bar to scroll Up/Dwn. Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page 36 any questions.

  • Page 47: Led Console Standard Service Menus

    Tests the console LEDs. Successively press the OK key to DISPLAY TEST verify each group of LEDs and verify that all LEDs illuminate. Press Back to exit the test. Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page 37 any questions.
  • Page 48 Active Status Light: Service and maintenance status light. Motor controller, motor controller unit, or motor controller module: used on treadmills, con- tains the LPCA and motor controller functionality. Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page 38 any questions.

  • Page 49: Club Settings Menu (5651565)

    (MCU). On self-powered units, it is the lower PCA console to base function inter- face. Emergency Stop: Safety clip and lanyard attached to the stop switch to immediately turn off power bringing the treadmill to a stop. Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page 39 any questions.
  • Page 50 Either enabled or disabled, the setting allows the unit to access specialized fitness tests designed for police, fire fighters and the HIDDEN PROGRAMS military. Default: disabled Elliptical Fitness Crosstrainer Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page 40 any questions.

  • Page 51: Information Display

    TRM800 version 1 treadmills mfg. dates 2010 thru 2014. TRM800 version 1 treadmills mfg. dates 2010 thru 2014. Printed circuit assembly, generally referred to as either an upper PCA or lower PCA. Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page 41 any questions.
  • Page 52 The console upper base software version information. MAIN CONSOLE SW* *P31 console only. Treadmill Alternating Current: electric current which periodically reverses direction between positive and negative polarity. Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page 42 any questions.
  • Page 53 (1)  Only used on products with the ASL feature. Not included on the EFX600 series, the TRM600 series, or the TRM800-10 (TRM10/GEN06) series products. (2)  TRM600 series treadmills only. Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page 43 any questions.

  • Page 54: Touchscreen Console Standard Service Menus

    LAN equipment carrying the Wi-Fi logo have been interoperability tested for compatibility with one (or more) 802.11 standards, and certified by the Wi-Fi Alliance to be sold under the Wi-Fi brand. Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page 44 any questions.

  • Page 55: About Menu

    Log). ABOUT MENU DESCRIPTION menu: About > Event Log The Event Log contains all connectivity errors and service main- Event Log tenance error codes. Preva Business Suite Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page 45 any questions.
  • Page 56 Network Time Protocol (NTP) is a networking protocol for clock synchronization between computer systems over packet-switched, variable-latency data networks. Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page 46 any questions.

  • Page 57: Equipment Usage Menu

    Menu: Service menu (51765761) > Settings > Maintenance Provides machine maintenance related information including: routine maintenance due status, machine operating condition, and ASL state. Adaptive Motion Trainer Upright Bike Recumbent Bike Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page 47 any questions.
  • Page 58       • Treadmills: A belt rating of 0 or 1 will cause a blue pulsing ASL light indicating that there is a problem with the running belt/- deck and is in need of servicing or replacement. Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page 48 any questions.

  • Page 59: System Settings Menu

    System Settings > Connectivity > Network Type Settings: Wired, Wi-Fi Default: Wired     » Network Type To connect to a network: 1. Select Network Type > Wired (or Wi-Fi) > Go. Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page 49 any questions.
  • Page 60 Default: ON Show (enable) the Browser app. menu: System Settings > Display > News Reader Range: ON/OFF     » News Reader Default: ON Show (enable) the News Reader app. Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page 50 any questions.
  • Page 61 Export/Import channel mapping using a USB .flash drive. Channels menu: System Settings > Audio Settings Specify the workout duration and equipment Limits for your Audio Settings menu facility. Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page 51 any questions.
  • Page 62 Bluetooth is a wireless technology standard for exchanging data over short distances (using short-wavelength UHF radio waves in the ISM band from 2.4 to 2.485 GHz from fixed and mobile devices, and building personal area networks (PANs). Contact Precor Customer Support at support@precor.com or 800.786.8404 with Page 52 any questions.
