Experience™ Series 700 Line Treadmill
Assembly Guide
Equati on 1: E nglis h

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Experience Series 700 Line and is the answer not in the manual?

Questions and answers

Related Manuals for Precor Experience Series 700 Line

Summary of Contents for Precor Experience Series 700 Line

  • Page 1 Experience™ Series 700 Line Treadmill Assembly Guide Equati on 1: E nglis h...

  • Page 3: Treadmill Assembly Guide

    Treadmill Assembly Guide Follow the steps in the order listed in this assembly guide. For more product information, visit us at www.precor.com. WARNING At least two people are required to assemble the equipment. DO NOT attempt assembly by yourself. Assembly requirements Important Before you fully tighten a fastener, check that its head is flush with the surface of the equipment.

  • Page 4: Hardware Kit

    Hardware kit Component Quantity Torque Component Quantity Torque Washer Plastic grommet (3/8-inch) (1/4-inch) Self-tapping pan head screw Washer (3/8-inch) 12 (1/4 x 1-inch) Self-tapping pan head screw Button head screw 25 ft-lb (1/4 x .75-inch) (3/8 x 1-inch) Hex head cap screw 25 ft-lb (3/8 x 5/8-inch) Note There may be extra hardware included with the treadmill.

  • Page 5: Begin Assembly

    Begin Assembly WARNING DO NOT attempt to connect electrical power until all assembly procedures are complete and console is properly installed. 4. Position the right upright support near the base frame and route the data cable Important Before unpacking the treadmill, follow the ramp assembly instructions inside of the base side cover and up through the right upright.
  • Page 6 To attach the dash: To complete the dash assembly: With assistance, set the dash assembly on top of the upright supports. Remove the two screws from the back of the dash cover. Remove the dash cover and set it aside with the screws. Note The dash slips down into the uprights.
  • Page 7 4. Fit the tread arm into the heart rate bar and against the dash assembly. To attach the heart rate bar: Attach it using two screws and two washers . Use a hex key to Position the heart rate bar assembly against the dash frame and attach it using partially tighten the screws.

  • Page 8: Touchscreen Consoles Only

    Touchscreen consoles only To attach the filter to the drive power cable: Table 1 Disconnect the existing power cable from the drive unit, power filter, and ground Position Connector terminal. Then completely remove it from the treadmill. Drive input connectors Brown lead with quick-connect terminal Blue lead with quick-connect terminal Green and yellow lead with quick-connect terminal...
  • Page 9 Pass the lower end of the TV cable through the right-hand grommet, and insert it To install the accessory jack panel: into the connector inside the jack panel. Use a 7/16-inch torque wrench to Remove the screws securing the blank plate at the right-front corner of the tighten the connectors to 30 in-lb.
  • Page 10 To attach the safety key assembly: 4. Insert two grommets into each of the dash arms, just above each upright support. Fit the bottom part of the safety key assembly onto the bottom of the dash assembly and heart rate arms. Position the top piece of the safety key assembly on top of the bottom part.

  • Page 11: Console Installation

    Console installation Level the treadmill To attach a console, refer to the installation instructions shipped with your console. Important Adjust only one rear foot at a time. DO NOT extend the adjustable feet more Once you have attached all the cables, follow the steps below to complete assembly than 3/4 inch (2 cm).

  • Page 12: Adjust The Running Belt Tracking

    Important During this functional test, if there is noticeable hesitation of the running belt with each foot plant, check the Running Belt Tension procedure in the Maintenance Guide that came in your treadmill box or on our website at www. precor.com.
  • Page 13 (refer to Adjusting the Running Belt section). Important Failure to align the belt may cause the belt to tear or fray, which is not covered by the Precor Limited Warranty. To test the reset switch: Press STOP to stop the belt.

  • Page 14: Safety Code

    Important The default setting for this feature is ON. An administrator can turn off this requires the exerciser to enter a code (1 2 3 4) on the keypad before the treadmill feature in the System Settings; however, Precor recommends it remain ON. will operate.
  • Page 16 700 Line Treadmill Assembly Guide | P/N 304387-101 rev A, ENU ©2016 Precor Incorporated | August 2016...
