1. Choose Draw > Line.
2. Take the end of an arc as the start point of line.
3. Specify the length of the line.
Endpoint of previous arc (A) and length of the line (B).

12.2 Arc Tool

Command line ARC
An arc is a portion of a circle. The default method for drawing an arc is to specify three points—the
start point, a second point, and the endpoint. You can draw arcs using any of the following methods:

Three points on an arc

Start point center point endpoint

Start point center point included angle

Start point center point chord length

Start point endpoint included angle

Start point endpoint starting direction

Start point endpoint radius

Center point start point endpoint

Center point start point included angle

Center point start point chord length

12.2.1 Draw Arcs by Specifying Three Points

Tormach® CNC Scanner
Drawing Tools
