3-4-2 Optional Peripherals/Peripheral Connection
Check if the fixing belts are loosen. If it is, tighten the belts again to secure the peripheral(s). If
necessary, remove the peripheral from the device room to tighten the belts.
3-4-2-1 Approved on-board peripherals
Refer to Section 5-3 Peripheral
14
Belts
Figure 3-6 How to Hold Peripherals
Compatibility.
Section 3-4 - Completing the Installation
(cont'd)
Connect the related cables
between the peripheral and
LOGIQ 7 if they are NOT con-
Belts
nected each other.
Belts
