8-2-10-3

Computer Name and Connection Settings

1.) Touch Utility > Connectivity.
2.) Click on TCP/IP.
3.) Type Computer Name.
The computer name is unique. Check the scanner serial Number printed on the label located at the rear
NOTICE
lower side of the scanner. When 123456YM1 (for example) is printed, L7-123456YM1 must be entered
as a computer name.
4.) Verify that Enable DHCP has no check mark. If checked, remove the mark.
5.) Check if Computer name, IP Address, Subnet Mask, and Default Gateway are proper ones
which you wrote down in section 8-2-6-4, Saving Connectivity.
If the "Save settings" is NOT performed, you can NOT enter the new patient screen!!
NOTICE
6.) Click on OK for confirmation dialog box.
8-36 Section 8-2 - Software Loading Procedures for BT09 (R8.x.x or later)
14
Figure 8-94 TCP/IP
Figure 8-95 OK
