6-3-1 Brake Function Adjustment
4.) Adjuster of the rear caster is also located on the caster linkage joint as shown.
5.) Turn the adjuster so that the caster lock lever is in the ceter position, as same as the front caster,
and the link is securely in place.
14
(cont'd)
Adjuster Nut
Figure 6-7 Rear Caster Adjuster Location
Section 6-3 - Caster Brake/Swivel Function Adjustments
Link
LOGIQ™ 7 S M
ERVICE ANUAL
Rear Caster
Lock Arm
Boss
6-7
