btsr SMART MATRIX WARP Operating Manual page 76

TS5 mode with "Bars" priority
TENS H
CREEL #A
BAR #B
SEN #C
TENS L
CREEL #A
BAR #B
SEN #C
PEAK H
CREEL #A
BAR #B
SEN #C
PEAK L
CREEL #A
BAR #B
SEN #C
NO YARN
CREEL #A
BAR #B
SEN #C
ERR EEP
CREEL #A
BAR #B
SEN #C
ERR OUT
CREEL #A
BAR #B
SEN #C
ERR TS5
CREEL #A
BAR #B
SEN #C
The BAR and SEN indication are replaced by ROW and COL, if the IDENTIFY function was
programmed with Row or Column "Priority". If the PROGRESSIVE mode has been set on the
OPTIONS menu, then instead of XXX#B + SEN#C the progressive number of the sensor will
appear.
Tens error, H Creel #A Bar #B Sensor #C
Tens error, L Creel #A Bar #B Sensor #C
Peak error, H Creel #A Bar #B Sensor #C
Peak error, L Creel #A Bar #B Sensor #C
No Yarn error, Creel #A Bar #B Sensor #C
EEprom data error, Creel #A Bar #B Sensor #C
Stop output error, Creel #A Bar #B Sensor #C
Communication error with TS5, Creel #A Bar #B Sensor #C
SMART MATRIX
SMART MATRIX Error Message
