Lamps Test
To select the lamp you may use the "shortcut" buttons or press in sequence the rotary selector.
SETUP
→
TEST COM
Enter the
SETUP
menu.
Select
TEST
COM.
Select
COL (ROW) (BAR) LAMP
out the test.
The display will show the lamps map.
Select the desired Creel and lamp.
The red led shall flash on the selected ACT/D module.
SMART MATRIX
Lamps Test
→
COL (ROW) (BAR) LAMP
or
CREEL LAMP
to carry
- 2-30 -
