To select the sensor coordinates (Creel, Column and Row) you may use the lower "shortcut" buttons
or press in sequence the rotary selector.
Shortcut Buttons available to Speed-up the Selection
Creel Column Row
OFFSET
YES to confirm the operation.
OFFSET operation completed.
It selects all sensors of selected Creel/Column/Row.
It toggles the sensors selection status within the selected
Creel/Column/Row.
It clears all selections.
SMART MATRIX
to carry out the calibration.
Offset TS5/TS7
