Laser Thermal Optical PTZ Camera



Copy duration: click the copy icon
the day to one or several other days.

Delete duration: click "Delete All" above the timeline to delete all the durations.
Select any duration and click "Delete" on the popup window or above the timeline to
delete the duration.
Note: Select any duration with a mouse, and drag the blue bar on the timeline as a whole
without changing the length of recording duration
Click "Save" to validate setting.
5)

7.3 Snapshot

After configuring scheduled snapshot, the camera will perform different snapshot tasks
automatically in the configured durations and save the pictures in the storage card.
Configuration steps are shown below:
1) Go to Settings > Storage > Storage Management to configure disk full strategy and
format the storage card recognized by the camera. If formatting is successful, the Status
will turn "Normal" which means the storage card can be used normally;
2) Go to Settings > Storage > Snapshot to configure;

Format: only support .jpeg format.

Resolution: same as that of current main stream.

Quality: the quality of captured image.
Click any duration and there will be small white squares on the 2 ends of it. Put
the mouse on any whit square, left-click and drag the edit the start time and end
time.
Select the timeline of any day and delete the default blue bar. Left click on the
mouse and drag on the timeline from left to right to form a blue bar, above
which it shows the start time and end time.
behind the timeline and copy the durations on
93
User Manual
