HD Mini Dome Camera
5.1.3

Focus

Focusing is the process of controlling a beam of light or particle flow and trying to gather it
to a point. It is necessary to form images. Adjustment of focus mode will help obtaining
optimum and clear target images.

Focus Mode: Select a mode from the dropdown list by request. The default mode is
"Single Focus".

Min Focus Distance: It is the minimum focus distance. When the distance is shorter than
this, the lens will be unable to focus automatically and clearly. Select a value from the
dropdown list.
 Focus Area: Select focus area manually, options including "Center", "2/3 from bottom",
"1/2 from bottom", "1/3 from bottom" and "Custom". If selecting "Custom", edit focus area
manually.
5.1.4

White Balance

Under different light conditions, there will be color cast in different images. White balance
adjustment can restore white objects to be white regardless of the color temperature of
the light source.
Select an option from the dropdown list of white balance mode. Suggest "Auto".




Manual: On the live view interface, click focus icons to perform manual focusing;

Continuous Focus: The camera will trigger auto focus once there is moving
object in the image.

Single Focus: The camera will trigger auto focus once the PTZ changes.
Manual: support R Gain and B Gain adjustment.
Auto 2: have a larger white balance range than "Auto 1", though both are auto mode.
Lock White Balance: lock current color correction matrix.
Picture 5-3 Focus
Picture 5-4 White Balance
37
