CABLE TERMINATION
4
Center conductor processing.
(1) Remove of the center conductor as shown.
(2) Chamfer the center conductor.
Tools
Note
Installation
Submission Prohibited
NEC Internal Use Only
Center conductor
•
nipper
•
file, etc.
Do not damage the center conductor.(burr, etc.)
1 mm
6 mm ± 1
Center conductor
6-7
NWD-107460-02E
